XCMG / XZ235S
XCMG equipment / Product profile
Horizontal Directional Drilling Rig
XZ235S
XCMG XZ235S — Horizontal Directional Drilling Rig. Review published parameters and request the configuration for your destination market from XEMACH.
Max.Reaming Diameter600 mm
Max.Thrust-pull Force235 kN
Engine Power110 kW
Engine Model6BT5.9-C150 一
Reference data from XCMG Global. Final market configuration must be confirmed.
XCMG Global ↗ · Source checked:
01
Overview
Published reference specifications
XCMG XZ235S — Horizontal Directional Drilling Rig. Review published parameters and request the configuration for your destination market from XEMACH.
Max.Reaming Diameter: 600 mm · Max.Thrust-pull Force: 235 kN · Engine Power: 110 kW · Engine Model: 6BT5.9-C150 一
Reference data from XCMG Global. Final market configuration must be confirmed.
02
Technical specifications
Values and units are preserved as published. Missing speed or version information is not inferred.
Engine ＋
| Item | Value | Unit |
|---|---|---|
| Engine | Not published | / |
| Rated power | Not published | kW |
| Power head Max. thrust-pull force | Not published | kN |
| Power head Max. thrust-pull speed | Not published | m/min |
| Power head Torque | Not published | N·m |
| Power head Max. rotation speed | Not published | r/min |
| Engine Power | 110 | kW |
| Engine Model | 6BT5.9-C150 | 一 |
| Max.Torque | 6500 | N ·m |
Hydraulic system ＋
| Item | Value | Unit |
|---|---|---|
| Mud pump Max. flow | Not published | L/min |
| Mud pump Max. pressure | Not published | MPa |
| Max.Mud Flow | 250 | L/min |
| Max.Mud Pressure | 8 | MPa |
Working Parameters ＋
| Item | Value | Unit |
|---|---|---|
| Crane Lifting weight | Not published | t |
| Crane Lifting moment | Not published | t•m |
| Recommended drill pipe | Not published | mm×m |
| Max. entry angle | Not published | ° |
| Max. back reaming diamete | Not published | mm |
| Weight | Not published | t |
| Max.Thrust-pull Force | 235 | kN |
| Max.Thrust-pull Speed | 55 | m/min |
| Max.Rotation Speed | 230 | r/min |
| Drill Pipe | φ60×3 | mm×m |
| Max.EntryAngle | '12-20 | 一 |
| Max.Reaming Diameter | 600 | mm |
| Weight | 9500 | kg |
Dimensions ＋
| Item | Value | Unit |
|---|---|---|
| Outline dimensions | Not published | mm |
| Dimensions（L×W×H） | 6800×2200×2300 | mm |
03
Dimensions & working range
04
Documents
The same original PDF is shared by all six language versions.
No model-specific document has been verified for publication. Ask us for the applicable brochure or maintenance manual.
