XCMG / ZL50GN
XCMG equipment / Product profile
Wheel Loader
ZL50GN
A wheel loader for earthmoving, aggregate handling and material loading. This page retains the existing XEMACH configuration, with grouped working, engine, chassis and dimension data.
Rated operating load5000 kg
Max. horse power160 ± 5 kW
Bucket capacity2.5 ~ 4.5 m³
Machine weight17500 ± 300 kg
Existing XEMACH configuration retained. Do not combine its values with another market version.
XEMACH ↗ · Source checked:
01
Overview
Published reference specifications
A wheel loader for earthmoving, aggregate handling and material loading. This page retains the existing XEMACH configuration, with grouped working, engine, chassis and dimension data.
Rated operating load: 5000 kg · Max. horse power: 160 ± 5 kW · Bucket capacity: 2.5 ~ 4.5 m³ · Machine weight: 17500 ± 300 kg
Existing XEMACH configuration retained. Do not combine its values with another market version.
Original manufacturer description (English)
ZL50GN wheel loader is the latest cross-generation product developed by XCMG on the basis of the globalized technologic resources.Focusing on the customer value and emphasizing the customer experiences, XCMG’s new generation loader boasts outstanding advantages (such as efficiency) in the fields of engineering constructions, aggregate yards, and coal logistics.
02
Technical specifications
Values and units are preserved as published. Missing speed or version information is not inferred.
Working Parameters ＋
| Item | Value | Unit |
|---|---|---|
| Rated operating load | 5000 | kg |
| Bucket capacity | 2.5 ~ 4.5 | m³ |
| Dump clearance at maximum lift | 3100 ~ 3780 | mm |
| Reach at maximum lift | 1100 ~ 1220 | mm |
| Max. breakout force | 175 ± 5 | kN |
| Hydraulic cycle time – raise | ≤ 6 | s |
| Total hydraulic cycle time | ≤ 10.5 | s |
Performance ＋
| Item | Value | Unit |
|---|---|---|
| Machine weight | 17500 ± 300 | kg |
| Articulation angle | 38 | ° |
| Gradeability | 30 | ° |
| Travel speed – I gear (F/R) | 13/17 | km/h |
| Travel speed – II gear (F/R) | 41 | km/h |
| Optional | ZF Tranmission | — |
Dimensions ＋
| Item | Value | Unit |
|---|---|---|
| Wheel base | 3300 | mm |
| Tread | 2250 | mm |
| Working height (fully lifted) | 5580 | mm |
| Min. turning radius over tyres | 5925 ± 50 | mm |
| Tyre size | 23.5-25-16PR | mm |
| Overall machine dimension L×W×H | 8225 × 3016 × 3515 | mm |
Engine ＋
| Item | Value | Unit |
|---|---|---|
| Max. horse power | 160 ± 5 | kW |
| Model | WD10G220E21 | — |
| Emission standards | Emission 2 | — |
| Rated Power/Speed | 162/2200 | kW/rpm |
