XCMG / XCA130_E
XCMG equipment / Product profile
All Terrain Crane
XCA130_E
XCMG XCA130_E — All Terrain Crane. Review published parameters and request the configuration for your destination market from XEMACH.
Max. load capacity130 t
Max. hoist height92.5 m
Max.load moment4468 kN.m
Telescopic boom62 m
Reference data from XCMG Global. Final market configuration must be confirmed.
XCMG Global ↗ · Source checked:
01
Overview
Published reference specifications
XCMG XCA130_E — All Terrain Crane. Review published parameters and request the configuration for your destination market from XEMACH.
Max. load capacity: 130 t · Max. hoist height: 92.5 m · Max.load moment: 4468 kN.m · Telescopic boom: 62 m
Reference data from XCMG Global. Final market configuration must be confirmed.
Original manufacturer description (English)
XCA130-E is widely used in the all terrain crane market, including road and bridge construction, equipment installation, bridge construction, oilfield and petrochemical construction, etc
02
Technical specifications
Values and units are preserved as published. Missing speed or version information is not inferred.
Working Parameters ＋
| Item | Value | Unit |
|---|---|---|
| Max. load capacity | 130 | t |
| Telescopic boom | 62 | m |
| Number of axles | 5 | — |
| Max.load moment | 4468 | kN.m |
| Drive/Steering | 10×8×10 | — |
| Driving speed | 80 | km/h |
| Dead Weight in Travel State | 60000 | kg |
Dimensions ＋
| Item | Value | Unit |
|---|---|---|
| Max. hoist height | 92.5 | m |
| Dimensions | 11960×2550×3790 | mm |
Engine ＋
| Item | Value | Unit |
|---|---|---|
| Drive engine model | OM471LA | — |
| Drive engine power | 360 | kw |
| Emission standard | EU Stage V | — |
03
Dimensions & working range
04
Documents
The same original PDF is shared by all six language versions.
No model-specific document has been verified for publication. Ask us for the applicable brochure or maintenance manual.
