E Series
XE280E
XCMG XE280E — E Series. Review published parameters and request the configuration for your destination market from XEMACH.
Reference data from XCMG Global. Final market configuration must be confirmed.
XCMG Global ↗ · Source checked:
Overview
XCMG XE280E — E Series. Review published parameters and request the configuration for your destination market from XEMACH.
Bucket capacity: 1.3 m³ · Operating weight: 26850 Kg · Rated power: 145 kW/rpm · Engine model: Cummins B6.7
Reference data from XCMG Global. Final market configuration must be confirmed.
Original manufacturer description (English)
The XE280E cabin is designed to support increased productivity with a spacious comfortable operator environment. The pressurized cab is ISO-certified for your safety and offers a comfortable mechanical suspension seat with several storage compartments and a clear all-round view of yourjobsite. The reduced noise and vibration levels with automatic air-conditioning/climate-con-trol will make work more easy and comfortable. The XE280E is equipped with a Cummins B6.7 engine.Famous for its excellent fuel efficiency, reliability, and long service life, it combines exceptional power output and high torque at low revs. Selective Catalytic Reduction (SCR) technology - combined with a Diesel Particulate Filter (DPF) – ensures compliance with Stage V regulations.
Technical specifications
Values and units are preserved as published. Missing speed or version information is not inferred.
Working Parameters ＋
| Item | Value | Unit |
|---|---|---|
| Operating weight | 26850 | Kg |
| Bucket capacity | 1.3 | m³ |
| Travel speed | 5.2/3.3 | km/h |
| Swing speed | 10.6 | r/min |
| Bucket digging force | 176 | kN |
| Arm digging force | 125 | kN |
Engine ＋
| Item | Value | Unit |
|---|---|---|
| Rated power | 145 | kW/rpm |
| Engine model | Cummins B6.7 | — |
| Emission standard | Euro V | — |
| Maximum torque/speed | 847/1500 | N.m |
| Displacement | 6.7 | L |
Documents
The same original PDF is shared by all six language versions.
No model-specific document has been verified for publication. Ask us for the applicable brochure or maintenance manual.
