XCMG / XCR70_E
XCMG equipment / Product profile
Rough Terrain Crane
XCR70_E
XCMG XCR70_E — Rough Terrain Crane. Review published parameters and request the configuration for your destination market from XEMACH.
Max. load capacity70 t
Max. hoist height57.9 m
Max.load moment2028.6 kN.m
Telescopic boom45 m
Reference data from XCMG Global. Final market configuration must be confirmed.
XCMG Global ↗ · Source checked:
01
Overview
Published reference specifications
XCMG XCR70_E — Rough Terrain Crane. Review published parameters and request the configuration for your destination market from XEMACH.
Max. load capacity: 70 t · Max. hoist height: 57.9 m · Max.load moment: 2028.6 kN.m · Telescopic boom: 45 m
Reference data from XCMG Global. Final market configuration must be confirmed.
Original manufacturer description (English)
Optimal matching design of the complete machine, traveling in the confined and height-limited space, strong adaptability for hoisting; extra-large comfortable cab + intelligent auxiliary system makes lifting easier.
02
Technical specifications
Values and units are preserved as published. Missing speed or version information is not inferred.
Working Parameters ＋
| Item | Value | Unit |
|---|---|---|
| Max. load capacity | 70 | t |
| Telescopic boom | 45 | m |
| Number of axles | 2 | — |
| Max.load moment | 2028.6 | kN.m |
| Drive/Steering | 4×2×4/4×4×4 | — |
| Driving speed | 25 | km/h |
| Dead Weight in Travel State | 44520 | kg |
Dimensions ＋
| Item | Value | Unit |
|---|---|---|
| Max. hoist height | 57.9 | m |
| Dimensions | 14354×3290×3750 | mm |
Engine ＋
| Item | Value | Unit |
|---|---|---|
| Drive engine model | Cummins B6.7 | — |
| Drive engine power | 209 | kw |
| Emission standard | EU Stage V | — |
03
Dimensions & working range
04
Documents
The same original PDF is shared by all six language versions.
No model-specific document has been verified for publication. Ask us for the applicable brochure or maintenance manual.
